水泥回轉窯 Rotary Cement Kiln
回轉窯結構簡單，生產過程控制方便可靠、易損件少、運轉率高，是水泥廠煅燒高標號水泥的設備，同時也廣泛用于冶金、化工、建筑等行業。我廠生產的回轉窯結構堅固、運轉平穩、出窯產品質量高。
Rotary kilns are characterized by simple structure, easy control of productive process, few easily damaged parts, and high operation rate. They are equipment used in cement plants to calcine high-grade cement. Besides, they are widely used in metallurgy, chemical, construction and other industries. The rotary kilns manufactured by our factory enjoy advantages of firm structure, smooth operation, and high-quality production burnt in the kiln.
技術參數
| 規格 | 技術參數 | 主減速器 | 主電動機 | 擋輪形式 | 支撐數量 | 重量 | |||
| 轉速 | 坡度 | 產量 | 速比 | 功率 | 轉速 | ||||
| r/min | (%) | t.h | kw | r/min | t | ||||
| ф1.9/1.6×36 | 0.53-1.59 | 4 | 2.5-3 | 48.58 | 30 | 1200/400 | 機械 | 3 | 53 |
| ф2.1/1.8×36 | 0.5-1.51 | 4 | 4 | 163.36 | 30/10 | 1410/470 | 機械 | 3 | 75 |
| ф1.2×25 | 0.5-1.6 | 3 | 40.17 | 22 | 1200/120 | 機械 | 3 | 34 | |
| ф1.6×32 | 0.158-0.258 | 3 | 48.57 | 15 | 1200/120 | 機械 | 3 | 47 | |
| ф1.8×45 | 0.66-1.98 | 4 | 3.5 | 163.36 | 30/10 | 1410/470 | 機械 | 3 | 80 |
| ф2.2×50 | 0.125-0.125 | 3.5 | 4 | 157 | 30 | 1320/132 | 機械 | 3 | 132 |
| ф2.5×50 | 0.516-1.549 | 3.5 | 5.5 | 99.96 | 55 | 1320/440 | 機械 | 3 | 168 |
| ф3×48 | 0.3309-3.309 | 3.5 | 35 | 32.11 | 90 | 1000/100 | 機械 | 3 | 238 |
| ф3.2×50 | 0.398-3.975 | 3.5 | 50 | 4085 | 190 | 1500/150 | 機械 | 3 | 263 |
| ф3.3×50 | 0.391-3.91 | 3.5 | 50 | 27.707 | 190 | 1000/100 | 機械 | 3 | 282 |
| ф4×60 | 0.396-3.96 | 3.5 | 104 | 34.601 | 315 | 1000/100 | 液壓 | 3 | 488 |
| ф4.2×60 | 0.4165-4.165 | 3.5 | 116 | 35.526 | 420 | 1000/100 | 液壓 | 3 | 578 |
| ф4.3×62 | 0.398-3.98 | 3.5 | 125 | 35.714 | 420 | 1000/100 | 液壓 | 3 | 600 |
| ф4.8×74 | 0.35-4 | 4 | 208 | 42.226 | 630 | 1500/130 | 液壓 | 3 | 842 |
